Introducing the RDPC-MX Robotic Depalletizer

Pearson’s RDPC-MX Robotic Depalletizer is highly configurable and capable of handling a wide array of product types including RSC and HSC cases, pails, drums, jugs, jars and bottles up to 125 lbs and speeds of up to 30 products per minute.

All of Pearson’s Palletizers and Depalletizers use FANUC robotics with over 80,000 hrs of Mean Time Between Failures (MTBF) for minimal maintenance requirements and the flexibility to easily adapt to new pallet patterns or case sizes, making the cells a reliable choice for high-volume, 24/7 manufacturing and distribution environments. An intuitive user interface (HMI) further simplifies operation and minimizes training needs.

Configure the system to your specific needs with single or multiple depalletizing stations, single or multiple outfeeds, bar code reading, automatic pallet handling, and various fencing options.

Depal

Pearson’s RDPC-MX Robotic Depalletizer is highly configurable and capable of handling a wide array of product types including RSC and HSC cases, pails, drums, jugs, jars and bottles up to 125 lbs and speeds of up to 30 products per minute.

All of Pearson’s Palletizers and Depalletizers use FANUC robotics with over 80,000 hrs of Mean Time Between Failures (MTBF) for minimal maintenance requirements and the flexibility to easily adapt to new pallet patterns or case sizes, making the cells a reliable choice for high-volume, 24/7 manufacturing and distribution environments. An intuitive user interface (HMI) further simplifies operation and minimizes training needs.

Configure the system to your specific needs with single or multiple depalletizing stations, single or multiple outfeeds, bar code reading, automatic pallet handling, and various fencing options.

Especificaciones

Performance

Velocidad
Case Range -
Sellado
Operación Robótica

Construcción

Frame
Size -
Sellado
Operación Robótica

Cambio

Type

Easy-to-use pallet configuration tool to create, modify, copy or clear new pattern recipes on the HMI, optional automatic tool changeover.
Process -
Time -

Controls and Utilities

PLC Allen-Bradley OptixPanel 2800 Color HMI, Allen-Bradley PLC, Fanuc Robot Controller, y Compatible con PackML
IHM Allen-Bradley OptixPanel 2800 Color HMI, Allen-Bradley PLC, Fanuc Robot Controller, y Compatible con PackML
Compliance -
Air 80 psi
Power 460 VCA

Case Types Supported

Available Upgrade

Automatic Pallet Handling

Automatic pallet discharge and/or pick and placement and conveying to the pick station and out of the cell.

Lector de código de barras

Also known as a barcode scanner, integrating a bar code reader enables the automatic identification and tracking of pallets and their contents, for faster processing, reduced errors, and improved inventory management.

Low or High Temperature Package

Electrical enclosures located in cold and humid environments maintain better performance and longevity with the addition of a heater and drier package. In high-temperature environments, the addition of an air conditioner may be necessary for optimal performance.

Conexión Ethernet a nivel de planta

Un dispositivo de traducción de direcciones de red permite configuraciones de red Ethernet específicas en múltiples máquinas en la red de la planta y ofrece la capacidad de soporte remoto a través de conexiones VPN.

Washdown Requirements

Upgrade package for non-caustic, non-clean environments protecting against low-pressure jets of water from all directions.

Recursos

Videos Content
Case Study Content
USER CENTRIC DESIGN
Machine Operator

Machine operators that perform their tasks independently free up your maintenance team and keep lines running smoother. Yet frequent turnover, language barriers, and skill gaps in these positions pose significant challenges to operations teams.

Pearson’s HMI Centric Design puts your operators and technicians at the center of our design decisions. With an uncluttered design, intuitive navigation, interactive guides, live sensor maps and advanced maintenance features, the HMI has morphed into a personal assistant. Mechanical improvements to the machines focus on easier visibility, accessibility and ergonomics for an optimal user experience for varying abilities and experience levels.

  • Minimice el tiempo de capacitación de operadores y técnicos
  • Aumente la velocidad de cambio y recuperación de fallas
  • Promover un mejor mantenimiento de la máquina y prolongar la vida útil del equipo
